The latest progress and development prospects of high-safety lithium-ion
battery research are reviewed.
Abstract: The latest progress and development prospects of high-safety
lithium-ion battery research are reviewed. This article mainly introduces the
causes and mechanisms of thermal instability of lithium-ion batteries from the
high-temperature stability of electrolytes and electrodes, clarifies the
shortcomings of existing commercial lithium-ion battery systems at high
temperatures, and proposes the development of high-temperature electrolytes,
positive and negative electrode modifications, and External battery management,
etc. to design high-safety lithium-ion batteries. The technical prospects of
developing safe lithium batteries are prospected. 0 Introduction Lithium-ion
batteries have become a typical representative of a new type of energy due to
their low cost, high performance, high power, green environment and many other
advantages. They are widely used in 3C digital products, mobile power supplies,
power tools and other fields. In recent years, due to the intensification of
environmental pollution and the guidance of national policies, the demand for
lithium-ion batteries in the electric transportation market, mainly electric
vehicles, has continued to increase. In the process of developing high-power
lithium-ion battery systems, battery safety issues have attracted widespread
attention. , the existing problems urgently need to be further solved. The
temperature change of the battery system is determined by two factors: heat
generation and dissipation. Heat generation in lithium-ion batteries is mainly
caused by thermal decomposition and reactions between battery materials. Reduce
the heat of the battery system and improve the high temperature resistance of
the system, and the battery system will be safer. Different from the battery
capacity of small portable devices such as mobile phones and notebooks, which
are generally less than 2Ah, the power lithium-ion batteries used in electric
vehicles generally have a capacity greater than 10Ah. During normal operation,
the local temperature is often higher than 55°C, and the internal temperature
will reach more than 300°C. Under high-temperature or high-rate charge and
discharge conditions, the heat release of high-energy electrodes and the
increase in the temperature of flammable organic solvents will cause a series of
side reactions to occur, eventually leading to thermal runaway and battery
combustion or explosion [3]. In addition to thermal runaway caused by its own
chemical reaction factors, some human factors such as short circuit caused by
overheating, overcharging, and mechanical shock can also cause thermal
instability of lithium-ion batteries and cause safety accidents. Therefore, it
is of great practical significance to study and improve the high-temperature
performance of lithium-ion batteries. 1 Analysis of the causes of thermal
runaway Thermal runaway of lithium-ion batteries is mainly caused by the rise in
the internal temperature of the battery. Currently, the most widely used
electrolyte system in commercial lithium-ion batteries is a mixed carbonate
solution of LiPF6. This type of solvent has high volatility, low flash point,
and is very easy to burn. When an internal short circuit is caused by collision
or deformation, a large amount of heat will be generated, causing the battery
temperature to rise. When a certain temperature is reached, a series of
decomposition reactions will occur, destroying the thermal balance of the
battery. When the heat released by these chemical reactions cannot be evacuated
in time, the reaction will be accelerated and trigger a series of self-heating
side reactions. The temperature of the battery rises sharply, which is called
"thermal runaway", eventually causing the battery to burn and even explode in
severe cases. In general, the causes of thermal runaway in lithium-ion batteries
mainly focus on two major aspects: the thermal instability of the electrolyte
and the thermal instability of the coexistence system between the electrolyte
and the positive and negative electrodes. At present, from a large perspective,
safety lithium-ion batteries mainly take measures from two aspects: external
management and internal design, and control internal temperature, voltage, and
air pressure to achieve safety purposes. 2 Strategies to Solve Thermal Runaway
2.1 External Management 1) PTC (Positive Temperature Coefficient) Element:
Installing PTC elements in lithium-ion batteries takes into account the pressure
and temperature inside the battery. When the battery heats up due to
overcharging, the temperature inside the battery The resistance increases
rapidly to limit the current, reducing the voltage between the positive and
negative electrodes to a safe voltage, thereby realizing the automatic
protection function of the battery. 2) Explosion-proof valve: When the internal
pressure of the battery is too high due to abnormality, the explosion-proof
valve deforms and cuts off the leads placed inside the battery for connection,
stopping charging. 3) Electronic circuit: Battery packs of 2 to 4 cells can be
pre-embedded with electronic circuits to design lithium-ion protectors to avoid
overcharge and over-discharge, thereby avoiding safety accidents and extending
battery life. Of course, these external control methods have certain effects,
but these additional devices increase the complexity and production cost of the
battery, and cannot completely solve the battery safety problem. Therefore, it
is necessary to establish an inherent security protection mechanism. 2.2
Improved electrolyte system The electrolyte is the blood of lithium-ion
batteries. The properties of the electrolyte directly determine the performance
of the battery, and play an important role in the battery's capacity, operating
temperature range, cycle performance and safety performance. Currently, the most
widely used components of commercial lithium-ion battery electrolyte systems are
LiPF6, ethylene carbonate and linear carbonate. The first two are indispensable
components, and their use also creates certain limitations in battery
performance. At the same time, a large number of carbonate solvents with low
boiling point and low flash point are used in the electrolyte, which will break
down at lower temperatures. Flashover is a huge safety hazard. Therefore, many
researchers have tried to improve the electrolyte system to improve the safety
performance of the electrolyte. As long as the main battery materials (including
electrode materials, separator materials and electrolyte materials) do not
undergo disruptive changes in a short period of time, improving the stability of
the electrolyte is an important way to enhance the safety of lithium-ion
batteries. 2.2.1 Functional additives Functional additives have the
characteristics of small dosage and strong pertinence. That is to say, certain
macroscopic properties of the battery can be significantly improved without
increasing or basically increasing the cost of the battery and changing the
production process. Therefore, functional additives have become a research
hotspot in the field of lithium-ion batteries today and are one of the most
promising ways to solve the current flammability problem of lithium-ion battery
electrolytes. The basic function of the additive is to prevent the battery
temperature from being too high and limit the battery voltage within a
controllable range. Therefore, the design of additives is also considered from
the perspective of temperature and charging potential. Flame retardant
additives: Flame retardant additives can be divided into organophosphorus flame
retardant additives, nitrogen-containing compound flame retardant additives,
halogenated carbonate flame retardant additives, silicon flame retardant
additives and composite flame retardant additives according to different flame
retardant elements. 5 main categories. Organophosphide flame retardants: mainly
include some alkyl phosphates, alkyl phosphites, fluorinated phosphates and
phosphazene compounds. The flame retardant mechanism is mainly the chain
reaction of flame retardant molecules interfering with hydroxyl radicals, also
known as the free radical capture mechanism. The vaporization and decomposition
of the additive releases phosphorus-containing free radicals, which have the
ability to capture hydrogen radicals in the system to terminate the chain
reaction. Phosphate ester flame retardants: mainly include trimethyl phosphate,
triethyl phosphate (TEP), tributyl phosphate (TBP), etc. Phosphazenes such as
hexamethylphosphazene (HMPN), alkyl phosphites such as trimethyl phosphite
(TMPI), tris-(2,2,2-trifluoroethyl), phosphite (TT- FP), fluorinated phosphates
such as tris-(2,2,2-trifluoroethyl)phosphate (TFP),
bis-(2,2,2-trifluoroethyl)-methylphosphate (BMP) ,
(2,2,2-trifluoroethyl)-diethylphosphate (TDP), phenyloctylphosphate (DPOF), etc.
are all good flame retardant additives. Phosphate esters usually have relatively
high viscosity and poor electrochemical stability. The addition of flame
retardants not only improves the flame retardancy of the electrolyte, but also
has a negative impact on the ionic conductivity of the electrolyte and the cycle
reversibility of the battery. The solutions are generally: ① increase the carbon
content of the alkyl group; ② partially replace the alkyl group with an aromatic
(phenyl) group; ③ form a phosphate ester with a cyclic structure.
Organohalogenated substances (halogenated solvents): Organohalogenated flame
retardants mainly refer to fluorinated organic substances. When H in non-aqueous
solvents is replaced by F, its physical properties will change, such as lower
melting point, lower viscosity, and improved chemical and electrochemical
stability. Organic halogenated flame retardants mainly include fluorinated
cyclic carbonates, fluorinated chain carbonates and alkyl-perfluoroalkyl ethers.
OHMI and other studies comparing fluorinated ethers and fluorinated esters with
fluorinated compounds have shown that the 0.67mol/LLiClO4/EC+DEC+PC (volume
ratio 1:1:1) electrolyte with 33.3% (volume fraction) fluorinated compounds
added has a relatively good It has a high flash point and a reduction potential
higher than organic solvents EC, DEC and PC. It can quickly generate an SEI film
on the surface of natural graphite, improving the Coulombic efficiency and
discharge capacity of the first charge and discharge. Fluorine itself does not
have the free radical trapping function like the flame retardants mentioned
above, but only plays the role of diluting highly volatile and flammable
co-solvents. Therefore, it can only be used when its volume ratio in the
electrolyte accounts for the majority. (>70%), the electrolyte is
non-flammable. Composite flame retardants: Composite flame retardants currently
used in electrolytes include P-F compounds and N-P compounds. Representative
substances mainly include hexamethylphosphoramide (HMPA), fluorinated
phosphates, etc. Flame retardants exert their flame retardant effect through the
synergistic effect of two flame retardant elements. FEI et al. proposed two N-P
flame retardants, MEEP and MEE, whose molecular formulas are shown in Figure 1.
LiCF3SO3/MEEP:PC=25:75, the electrolyte can reduce the flammability by 90%, and
the conductivity can reach 2.5×10-3S/cm.
2) Overcharge additive: When a lithium-ion battery is overcharged, a series
of reactions will occur. The electrolyte components (mainly solvents) undergo
irreversible oxidation and decomposition reactions on the surface of the
positive electrode, producing gas and releasing a large amount of heat, which
leads to an increase in the internal pressure and temperature of the battery,
seriously affecting the safety of the battery. In terms of mechanism of action,
overcharge protection additives are mainly divided into two types: redox shuttle
type and electropolymerization type. In terms of additive types, they can be
divided into lithium halides and metallocene compounds. The overcharge additives
currently used in large-scale applications mainly include biphenyl (BP) and
cyclohexylbenzene (CHB). For redox anti-overcharge additives, the principle is
that when the charging voltage exceeds the normal cut-off voltage of the
battery, the additives begin to generate energy in the positive electrode.
Oxidation reaction, the oxidation product diffuses to the negative electrode,
and a reduction reaction occurs. The redox couple shuttles between the positive
and negative electrodes, absorbing excess charge. Its representative substances
include ferrocene and its derivatives, complexes of 2,2-pyridine and
1,10-phenanthroline of ferrous ions, and thianthrene derivatives. Polymerization
blocking additive to prevent overcharge. Representative substances include
cyclohexylbenzene, biphenyl and other substances. When biphenyl is used as an
anti-overcharge additive, when the voltage reaches 4.5~4.7V, the added biphenyl
polymerizes electrochemically, forming a conductive film on the surface of the
positive electrode, which increases the internal resistance of the battery,
thereby limiting the charging current and protecting the battery. . 2.2.2 Ionic
liquid Ionic liquid electrolyte is composed entirely of anions and cations.
Because the anions or cations are large in size, the interaction between anions
and cations is weak and the electron distribution is uneven. Anions and cations
can move freely at room temperature and are in a liquid state. Generally
speaking, they can be divided into imidazoles, pyrazole and pyridine, quaternary
ammonium salts, etc. Compared with ordinary organic solvents for lithium-ion
batteries, ionic liquids have five main advantages: ① High thermal stability and
no decomposition at 200°C; ② The vapor pressure is almost 0, so there is no need
to worry about bloating in the battery; ③ Ionic liquids are not flammable ,
non-corrosive; ④ high electrical conductivity; ⑤ good chemical or
electrochemical stability. AN et al. formulated PP13TFSI and 1molLiPF6EC/DEC
(1:1) into an electrolyte, which can achieve completely non-flammable effect.
Adding 2wt% LiBOB additive to this system can also significantly improve the
interface compatibility. The only problem that remains to be solved is the
conductivity of ions in the electrolyte system. 2.2.3 Choose a lithium salt with
good thermal stability. Lithium hexafluorophosphate (LiPF6) is the electrolyte
lithium salt widely used in commercial lithium-ion batteries. Although its
single property is not optimal, its comprehensive performance is the most
advantageous. However, LiPF6 also has its shortcomings. For example, LiPF6 is
chemically and thermodynamically unstable, and the following reaction will
occur: LiPF (6s) → LiF (s) + PF (5g). The PF5 generated by this reaction can
easily attack oxygen atoms in organic solvents. The lone pair of electrons on
the solvent leads to ring-opening polymerization of the solvent and cleavage of
the ether bond. This reaction is particularly serious at high temperatures.
Current research on high-temperature electrolyte salts is mostly focused on the
field of organic lithium salts. Representative substances mainly include boron
lithium salt and imide lithium salt. LiB(C2O4)2 (LiBOB) is a newly synthesized
electrolyte salt in recent years. It has many excellent properties, has a
decomposition temperature of 302°C, and can form a stable SEI film on the
negative electrode. Improve the performance of graphite in PC-based electrolyte,
but its viscosity is high and the resistance of the SEI film formed is large
[14]. The decomposition temperature of LiN (SO2CF3)2 (LiTFSI) is above 360°C,
its ionic conductivity at room temperature is slightly lower than that of LiPF6,
it has good electrochemical stability, and its oxidation potential is about
5.0V. It is the most studied organic lithium salt, but it The corrosion of
Al-based current collector is serious. 2.2.4 Polymer electrolyte Many commercial
lithium-ion batteries use flammable and volatile carbonate solvents. If leakage
occurs, it is likely to cause a fire. This is especially true for power
lithium-ion batteries with large capacity and high energy density. The use of
non-flammable polymer electrolytes instead of flammable organic liquid
electrolytes can significantly improve the safety of lithium-ion batteries.
Research on polymer electrolytes, especially gel polymer electrolytes, has made
great progress. It has been successfully used in commercial lithium-ion
batteries. According to the main polymer classification, gel polymer
electrolytes mainly include the following three categories: PAN-based polymer
electrolyte, PMMA polymer electrolyte, and PVDF-based polymer electrolyte.
However, gel polymer electrolytes are actually the result of a compromise
between dry polymer electrolytes and liquid electrolytes. Gel polymer batteries
still have a lot of work to do. 2.3 The positive electrode material can
determine that the positive electrode material is unstable when the charged
state voltage is higher than 4V, and is prone to thermal decomposition at high
temperatures to release oxygen. Oxygen and organic solvents continue to react to
generate a large amount of heat and other gases, reducing the safety of the
battery [2, 17-19]. Therefore, the reaction between the positive electrode and
the electrolyte is considered to be the main cause of thermal runaway. For
cathode materials, a common method to improve their safety is coating
modification. For example, surface coating of the positive electrode material
with MgO, A12O3, SiO2, TiO2, ZnO, SnO2, ZrO2 and other substances can reduce the
reaction between the positive electrode and the electrolyte after Li+ removal,
while reducing the oxygen release of the positive electrode and inhibiting the
phase change of the positive electrode material. , improve its structural
stability, reduce the disorder of cations in the crystal lattice, thereby
reducing the heat generated by side reactions during the cycle. 2.4 Carbon
materials Currently, power batteries with higher safety requirements usually use
spherical carbon materials with lower specific surface area, higher charge and
discharge platform, smaller charged state activity, relatively good thermal
stability and high safety. For example, mesocarbon microspheres (MCMB) or
spinel-structured Li9Ti5O12 have better structural stability than layered
graphite [20]. Current methods to improve the performance of carbon materials
mainly include surface treatment (surface oxidation, surface halogenation,
carbon coating, coating of metals and metal oxides, polymer coating) or the
introduction of metal or non-metal doping. 2.5 Separator The most widely used
separator in commercial lithium-ion batteries is still polyolefin material. Its
main disadvantages are heat shrinkage at high temperatures and poor electrolyte
wettability. In order to overcome these shortcomings, researchers have tried
many methods, such as looking for thermally stable materials instead, or adding
a small amount of Al2O3 or SiO2 nanopowder separators, which not only have the
function of ordinary separators, but also have the ability to improve the
thermal stability of the cathode material. effect. Polyimide nano-nonwoven
prepared by MIAO and others using electrospinning methodCloth separator.
Characterization methods such as DSC and TGA show that it can not only maintain
thermal stability at 500°C, but also have better electrolyte wettability than
Celgard separators. WANG et al. prepared an Al2O3-PVDF nanoscale composite
microporous membrane. The composite microporous membrane exhibits good
electrochemical performance and thermal stability and meets the requirements for
use as a lithium-ion battery separator. 3 Summary and Outlook Lithium-ion
batteries used in electric vehicles and energy storage have much larger
capacities than small electronic devices, and their use environments are more
complex. To sum up, we can see that its security performance is far from being
solved and has become a technical bottleneck in current applications. Follow-up
work needs to delve into the thermal effects that may result from abnormal
operation of the battery and explore effective ways to improve the safety
performance of lithium-ion batteries. Currently, the use of fluorinated solvents
and flame retardant additives is the main direction for developing safe
lithium-ion batteries. How to balance electrochemical performance and
high-temperature safety will be the focus of future research. For example,
develop high-performance composite flame retardants integrating P, N, F, and Cl,
develop organic solvents with high boiling points and high flash points, and
then prepare electrolytes with high safety performance. Composite flame
retardants and dual-functional additives will also become the future development
trend. For lithium-ion battery electrode materials, due to the different surface
chemical properties of the materials and the different sensitivity of the
electrode materials to the charge and discharge potential, it is impossible to
design all battery structures with one or a limited number of
electrodes/electrolytes/additives. Therefore, in the future, efforts should be
made to research and develop different battery systems for specific electrode
materials. At the same time, develop and construct polymer lithium-ion battery
systems with high safety or develop inorganic solid electrolytes with single
cation conductivity, fast ion transport, and high thermal stability. In
addition, improving the performance of ionic liquids and developing simple and
cheap synthesis processes are also important aspects of future research.
Read recommendations:
Coin Battery CR 1620
18650 lithium battery pack correct storage method.solar energy storage lithium ion battery 15kwh 48v
How does lithium polymer battery perform under extreme temperature conditions?
3.2v 230ah lifepo4 battery
CR1212 battery
360° FACTORY VR TOUR
Whatsapp
Tel
Email
TOP
